S6061-08-16-24 Standard Damper Actuator (Non Fail-Safe Damper Actuators) – Soloon Detail:
Features of S6061-08~24 Standard Damper Actuator (Non Fail-Safe Damper Actuators)
- Torque 08-16-24NM
- 2 or 3 points control or Modulating
- Actuator and damper shaft are bolt-on by screw.
- Maximum round shaft φ16 and square shaft 12*12mm.
- Direction of rotation can be setting.
- Manual Override
- With 2 auxiliary switches are optional
- Power supply AC/DC 24V or AC 230V
Technical Datasheet of S6061-08~24 Standard Damper Actuator (Non Fail-Safe Damper Actuators)
| Item |
Unit位 |
S6061-08DN(F) |
S6061-16DN(F) |
S6061-24DN/(F) |
| Torque |
Nm |
8 |
16 |
24 |
| Damper area |
m2 |
2 |
4 |
6 |
| Running time |
sec |
30~40 |
72~88 |
117~143 |
| Power supply |
V |
24VAC/DC；220VAC；110VAC |
| Frequency |
Hz |
50/60Hz
7.5W 50/60Hz |
| Running consumption |
W |
3.9W（24V）；4.8W（230V） |
| Maintaining consumption |
W |
0.4W（24V）；1.2W（230V） |
| Weight |
Kg |
1.25 |
| Control signal |
2/3 point |
| Position signal |
2 auxiliary switches |
| Rotation angle |
0~90º（max 93°） |
| Limited angle |
5～85º（per step 5º） |
| Auxiliary switch rating |
3（1.5）Amp 250V |
| Life cycle |
>70000 cycles |
| Noise level |
45dB(A) |
| Electrical level |
Ⅱ |
| Protection level |
IP44 or IP54 |
| Ambient Temperature |
-20~+50℃ |
| Ambient Humidity |
5~95%RH |
| Storage temperature |
-40~+70℃ |
| Certification |
CE UL（Except 230V） |
Wiring Diagram of S6061-08~24 Standard Damper Actuator (Non Fail-Safe Damper Actuators)
The damper actuator can be controlled by 2 or 3 point.
Auxiliary Switch of S6061-08~24 Standard Damper Actuator (Non Fail-Safe Damper Actuators)
There are 2 auxiliary switches of the actuator, and you can set the angle 0-90° (the factory sets a is 10° and b is 80°). It will output a on/off signal when the actuator rotates the setting angle.
Control Signal and Choose the Direction of Rotation of S6061-08~24 Standard Damper Actuator (Non Fail-Safe Damper Actuators)
The direction of rotation changes according to the direction of pin.
Outline and Dimension of S6061-08~24 Standard Damper Actuator (Non Fail-Safe Damper Actuators)
