S6063B Control Valve – Soloon Detail:
Technical Data of S6063B Control Valve
○ Nominal Pressure: 2.0Mpa
○ Valve body material: Forged Brass
○ End Connection: Threaded ISO7-1
○ Leakage: 0. 0.04% kvs
○ Flow Characteristic: A-B Equal Percentage，C-B Linear
○ Medium Temperature: Chilled/Hot water 2°C~90°C
Valve Flow Diagram of S6063B Control Valve
3-way valve body can be used mixing valve (port B and C is input, port A is output) or diverting valve (port A is input, port B and C is output).
Flow Characteristic of S6063B Control Valve
Dimensions of S6063B Control Valve
|
Size |
L(mm) |
H(mm) |
H1(mm) |
| 2-way |
3-way |
| DN20 |
69 |
93 |
19 |
44 |
| DN25 |
80 |
93 |
22 |
48 |
| DN32 |
92 |
93 |
28 |
53 |
| DN40 |
110 |
94 |
31 |
55 |
| DN50 |
125 |
99 |
38 |
63 |
| DN65 |
150 |
107 |
48 |
– |
Installation of S6063B Control Valve
Attention: Valve install downward forbid.
Valve can be installed onto supply or return pipe, in general, it recommend to install onto return pipe(it is better to control the water flow stable, and extend the use life of valve due to lower temperature of return water), meanwhile recommend to install filter and return valve before it.
