China S6061-02 Standard Damper Actuator (Non Fail-Safe Damper Actuators) Manufacturer and Supplier

Features of S6061-02 Standard Damper Actuator (Non Fail-Safe Damper Actuators)

Torque 02NM;
Power supply AC/DC 24V or AC 230V;
2 and 3 point control or Modulating;
Convenient install: Fix on throttle axis through the universal holding device;
Manual control: Manual control through buttons available in the case;
High reliability: The actuator itself has the ability to over-loading protect. It stops automatically without a limit switch;
Mechanical limit: A mechanical limit operator is placed inside;
Output signal: Output a signal amount 0-100%.

Item	S6061-02AN(F)/ 24V	S6061-02AN(F)/ 220V	S6061-02DN(F)/ 24V	S6061-02DN(F)/ 220V
Torque	2Nm
Damper area	0.5m²
Running time	45-55S		35-45S
Power supply	AC/DC24V 50/60Hz	AC230V 50/60Hz	AC/DC24V 50/60Hz	AC230V 50/60Hz
Operating power consumption	2.5W	2.5W	2W	1.5W
Wire size	4.5VA
Weight	0.6 Kg
Control signal	2-10V	0-10V	2/3 point
Angle of rotation	0~90°（Max 93º）
Rotate direction	L/R switch
Auxiliary switch rating	3（1.5）Amp 250V
Life cycle	>70 000
Noise	Max 45dB
IP level	IP54
Temperature	-20~+50℃
Humidity	5~95%RH
Storage temperature	-40~+70℃
Certificate	CE ——— CE CE
